Middle Atlantic: 19" Racks and technical furniture
Middle Atlantic Products offers an extensive product portfolio of Racks and cabinets with sophisticated features, such as extendable and rotatable rack to facilitate the work in cramped environments, amounting dividers numbered for optimal alignment of the devices, highly configurable thermal management for safe operation of the hardware or prepared and customized cable-management solutions
Rack planner to plan a rack easily and request and offer
Frame to Furniture
Preconfigured racks
|
Further rack-series can be found here |
|
Freestanding Racks
|
|
|
Mobile Racks
|
|
Wall Mounting Racks
|
|
Laminate Racks
|
Roll out rotating system
|
In-Cabinet Systems
|
|
|
Accessories
|
|
|
NEW: Frame to Furniture
where function meets form - technical furniture solutions
» more
Product Features
Save time and make the installation of your 19” rack or enclosure safer and more efficient with the right products from Middle Atlantic!
MAP systems will facilitate work for the integrator, increase equipment safety and offer a perfect appearance to the user.
Manufacturers of 19" racks and compartments are as many as stars in the sky. Most of them have their roots in telecommunication or electrical construction.
There are many manufacturers of 19" racks. Most of them have their roots in switchboard technology or telecommunication. MAP is different: they have their origin in the music and AV industry. MAP has developed its cleverly devised innovative product range with this background and based on their collected experience regarding the requirements of the equipment to be mounted in the racks. In addition to the aesthetic design and professional look of the racks, the focus of MAP is always on the needs of the integrator.
| Problem | Solution | |
|---|---|---|
| Often enough the location of an installation is not easy accessible. |
Many MAP products are shipped flat and can be mounted within minutes. Single parts can be transported more easily to areas of a building which are difficult to access. With many MAP products, housing and carrying system can be mounted separately from each other. This way, the racks can be preinstalled at the workshop. Afterwards, the final setup can be done quickly and easily on the location. |
  |
| Frequently, space is limited and free access to the back of the equipment for installation is difficult or even impossible |
For installations where space is limited, there are racks from MAP which slide out and rotate. This allows an easy access to the back of the equipment during installation and service |
  |
| The multitude of signal and power connections can result in a chaos of loose and tangled cables. |
A cleverly devised cable management system keeps your cables ordered and ensures a quick and safe installation. This becomes especially important when equipment has to be added to a rack at a later date or when servicing the rack |
 |
| Amplifiers and especially satellite receivers develop an enormous heat which has a negative influence on the operation of the equipment in the rack and can reduce its life span. |
An elaborate thermal management concept from single component coolers to high end temperature controlled enclosure cooling solutions increases the life span and performance of the equipment in the rack. Temperature is always kept at an ideal 29,5 °C. Research has shown that a temperature increase of only 5% will reduce the life span of a device by 40%td> |
 |
| Often consumer equipment which is not fit for 19” mounting has to be integrated into a rack. This causes difficulties regarding proper thermal management and equipment which is put loosely on shelves will give the rack an unprofessional look. |
For consumer devices, MAP offers shelves with customized face plates which are laser cut to fit perfectly around any device. The MAP database stores the dimensions of 10000 devices and is growing with every day. The customized faceplates contribute to a professional look of the rack and support a perfect thermal management. |
 |
| Working with cage nuts when installing the equipment can be a pain for the technician. Having to recognize towards the end of an installation that the installed equipment is offset for one cage hole is even more annoying |
MAP racks have threaded rack rails instead of cage nuts. In combination with the pilot head screws, installation becomes fast and simple offering enormous time saving potential. The rack units are numbered and marked on the rack rails, saving even more installation time and avoiding an offset installation of devices |
 |
These and other innovative and advantageous features set MAP off from other rack manufacturers. MAP racks offer professional solutions to the customer and make the work of the integrator easier and more efficient.
